Grundfos Multi-stage centrifugal pump stainless steel 1 1/4" 2,5A 400VAC type CRI 1-17 A CA I V HQQV
Part number 7039664
Downloads
Select your item below or order directly via
full product table
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price to pay excl. VAT
€2,434.00 / 1 pcs
€2,434.00 / pcs
Price to pay incl. VAT
€2,993.82 / 1 pcs
€2,993.82 / pcs
Available at supplier, please contact us
- Available on request, please call sales team
Frequently bought together
0080706
0100724
0080196
0412032
7002773
0075083
0412104
0410784
0080934
Technical details
-
Motor RPM2770
-
Maximum ambient temperature40 °C
-
Output Power1.5 HP
-
Pump bodystainless steel 316
-
IP valueIP55
-
Materialstainless steel
-
TypeCRI 1-17 A CA I V HQQV
-
Shaftstainless steel 316
-
Temperature range-20°C - 90°C
-
Frequency50 Hz
-
Material impeller 1stainless steel 304
-
Voltage400VAC
-
Impellers17
-
Ampere2,5 A
-
Suction1 1/4 "
-
Size1 1/4"
-
Max flow rate2.4 m³/h
-
EAN4019305784337
-
Part number7039664
-
ManufacturerGrundfos
Dimensions
-
Cb-150 mm
-
Cb-250 mm
-
H-1766 mm
-
L162 mm
-
W-1210 mm
-
ØDi-135 mm
-
ØDi-235 mm
Similar products
Product description
Grundfos CRI pumps are vertical, non-self-priming, multistage, in-line, centrifugal pumps for installation in pipe systems and mounting on a foundation, suitable for industrial applications. This design provides a more compact pump design and pipework. CR pumps are designed for a variety of applications ranging from the pumping of potable water to the pumping of chemicals. The pumps are therefore suitable for a wide range of pumping systems where the performance and material of the pump meet specific demands.
