Grundfos Variable speed circulation pump cast iron DN80 flange 10bar 3.17A 230VAC black/red WRAS type MAGNA3 80-80F (360)

Part number 7039823
Shop the full range here
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price to pay incl. VAT €1,543.65 / 1 pcs
€1,543.65 / pcs
Price to pay excl. VAT (€1,255.00 / 1 pcs)
Box qty:
1 pcs
MSQ:
1 pcs
Available at supplier, please contact us
pcs

Frequently bought together

Tie-Down stake plastic 16-20 mm 15cm black
Tie-Down stake plastic 16-20 mm 15cm black

€0.15
Rain Bird Tie-Down stake plastic 16 mm brown type C12
Rain Bird Tie-Down stake plastic 16 mm brown type C12

€0.40
Profec Flat hose PVC 32 mm 9bar blue 100m type Medium Duty
Profec Flat hose PVC 32 mm 9bar blue 100m type Medium Duty

€3.13
Profec Socket PVC-U 25 mm glue socket 16bar grey KIWA
Profec Socket PVC-U 25 mm glue socket 16bar grey KIWA

€0.53
Spray nozzle 180° plastic 3/8WW male thread 2,25 mm 180° black
Spray nozzle 180° plastic 3/8WW male thread 2,25 mm 180° black

€0.28
Profec Elbow 90° PVC-U 40 mm glue socket 16bar grey
Profec Elbow 90° PVC-U 40 mm glue socket 16bar grey

€1.57
Rain Valve box circular PP black/green type Circular RN15
Rain Valve box circular PP black/green type Circular RN15

€4.39
VDL Adaptor rubber reinforced with nylon 3/8WW female thread black
VDL Adaptor rubber reinforced with nylon 3/8WW female thread black

€0.15
Profec Sealing tape PTFE 12 mm white 12m DVGW
Profec Sealing tape PTFE 12 mm white 12m DVGW

€1.67
Profec Wormdrive hose clip stainless steel 304 16 mm x 27 mm type W4 12 mm
Profec Wormdrive hose clip stainless steel 304 16 mm x 27 mm type W4 12 mm

€0.88

Technical details

  • Colour
    black/red
  • Maximum ambient temperature
    40 °C
  • Type
    MAGNA3 80-80F (360)
  • Pressure
    10 bar
  • Impellers
    1
  • Ampere
    3.17 A
  • Material impeller 1
    fibreglass-reinforced PES
  • Voltage
    230VAC
  • Connection
    flange
  • Minimum medium temperature (continuous)
    -10 °C
  • Frequency
    50 Hz
  • Size
    DN80
  • Approval
    WRAS
  • Minimum ambient temperature
    0 °C
  • Max. temperature
    110 °C
  • Pump body
    cast iron
  • Material
    cast iron
  • EAN
    4019305785563
  • Part number
    7039823
  • Manufacturer
    Grundfos

Barcode

4019305785563

Variants

Part number
Price
Box qty
MSQ
Stock
7039796
€1,255.00
1
1
7039797
€1,255.00
1
1
7039798
€1,255.00
1
1
7039799
€1,255.00
1
1
7039800
€1,255.00
1
1
7039801
€1,255.00
1
1
7039802
€1,255.00
1
1
7039803
€1,255.00
1
1
7039804
€1,255.00
1
1
7039805
€1,255.00
1
1
7039806
€1,255.00
1
1
7039807
€1,255.00
1
1
7039808
€1,255.00
1
1
7039809
€1,255.00
1
1
7039810
€1,255.00
1
1
7039811
€1,255.00
1
1
7039812
€1,255.00
1
1
7039813
€1,255.00
1
1
7039814
€1,255.00
1
1
7039815
€1,255.00
1
1
7039816
€1,255.00
1
1
7039817
€1,255.00
1
1
7039818
€1,255.00
1
1
7039819
€1,255.00
1
1
7039820
€1,255.00
1
1
7039821
€1,255.00
1
1
7039822
€1,255.00
1
1
7039823
€1,255.00
1
1
7039824
€1,255.00
1
1
7039825
€1,255.00
1
1
7039826
€1,255.00
1
1
7039827
€1,255.00
1
1
7039828
€1,255.00
1
1
7039829
€1,255.00
1
1
7039830
€1,255.00
1
1
