Profec Flange adaptor ductile iron (GGG40) epoxy coating 160 mm x DN150 ring seal x DIN flange 10bar DN150 blue PN10/16 type E-KS

Part number 0399023

Downloads

Shop the full range here
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price to pay incl. VAT €190.63 / 1 pcs
€190.63 / pcs
Price to pay excl. VAT (€154.98 / 1 pcs)
Box qty:
60 pcs
MSQ:
1 pcs
pcs

Frequently bought together

Rain Bird Tie-Down stake plastic 16 mm brown type C12
7021563
Rain Bird Tie-Down stake plastic 16 mm brown type C12
Op voorraad

€0.40
Tie-Down stake plastic 16-20 mm 15cm black
7031973
Tie-Down stake plastic 16-20 mm 15cm black
Out of stock

€0.15
Jason Reducer socket PP 32 mm x 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
0706133
Jason Reducer socket PP 32 mm x 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
Out of stock

€3.12
Profec Pipe clamp PP 40 mm black type 3
0110954
Profec Pipe clamp PP 40 mm black type 3
Op voorraad

€1.06
Profec Nr. 280 Nipple cast iron galvanised 1/2" male thread 25bar DVGW
1028004
Profec Nr. 280 Nipple cast iron galvanised 1/2" male thread 25bar DVGW
Op voorraad

€1.48
Profec Wormdrive hose clip stainless steel 304 12 mm x 20 mm type W4 12 mm
0464481
Profec Wormdrive hose clip stainless steel 304 12 mm x 20 mm type W4 12 mm
Op voorraad

€0.89
Profec Socket PVC-U 25 mm glue socket 16bar grey KIWA
0110647
Profec Socket PVC-U 25 mm glue socket 16bar grey KIWA
Out of stock

€0.53
Jason Elbow 90° PP 32 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
0706532
Jason Elbow 90° PP 32 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
Op voorraad

€3.24
Mini plug valve PP 16 mm x 1/2" barbed x male thread black
7022104
Mini plug valve PP 16 mm x 1/2" barbed x male thread black
Out of stock

€0.87
Profec Ball valve PVC-U 25 mm glue socket 16bar DN20 grey type Safe 525
0112141
Profec Ball valve PVC-U 25 mm glue socket 16bar DN20 grey type Safe 525
Out of stock

€7.73

Technical details

  • PCD
    240 mm
  • Material
    ductile iron (GGG40)
  • Holes
    8
  • Bolt hole
    23 mm
  • Connection
    ring seal x DIN flange
  • Material seal
    EPDM
  • Material housing
    ductile iron (GGG40)
  • Flange
    PN10/16
  • Pressure
    10 bar
  • PCD
    240 mm
  • DN
    150
  • Type
    E-KS
  • Surface treatment
    epoxy coating
  • ØDi-1
    160 mm
  • Thickness
    16 mm
  • Colour
    blue
  • Outer ø
    285 mm
  • O
    23 mm
  • DIN Standard
    DIN 2576
  • EAN
    4019305096126
  • Part number
    0399023
  • Manufacturer
    Profec

Barcode

4019305096126

Variants

Part number
Price
Box qty
MSQ
Stock
0399021
€87.36
120 pcs
1 pcs
(23)
0399023
€154.98
60 pcs
1 pcs
(11)
