Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 5.5A 230VAC black/red WRAS type MAGNA3 100-100F (450)

Part number 7039829
Skip image gallery
Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 5.5A 230VAC black/red WRAS type MAGNA3 100-100F (450)
Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 5.5A 230VAC black/red WRAS type MAGNA3 100-100F (450)
Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 5.5A 230VAC black/red WRAS type MAGNA3 100-100F (450)
Select your item below or order directly via full product table
Power
MWC
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price excl. VAT £5,952.00 / 1 pcs
£5,952.00 / pcs
Price incl. VAT £7,142.40 / 1 pcs
£7,142.40 / pcs
Available at supplier, please contact us - Available on request, please call sales team
pcs
Box qty:
1 pcs
MSQ:
1 pcs
  • Fast, free shipping on orders over £350*
  • Your trade partner in water technology
  • 9.1/10 Read reviews

Frequently bought together

Reducer bush PVC-U 32 mm x 20 mm glue spigot x glue socket 16bar grey
0160735
Reducer bush PVC-U 32 mm x 20 mm glue spigot x glue socket 16bar grey

£0.92
Rubber plug rubber reinforced with nylon 50 mm
0211053
Rubber plug rubber reinforced with nylon 50 mm

£1.64
Profec Reducer socket PE100 40 mm x 32 mm spigot SDR11 10bar 16bar black DVGW
0302114
Profec Reducer socket PE100 40 mm x 32 mm spigot SDR11 10bar 16bar black DVGW

£4.02
Profec Reducer T-piece 90° PVC-U 75 mm x 50 mm x 75 mm glue socket 16bar grey
0110305
Profec Reducer T-piece 90° PVC-U 75 mm x 50 mm x 75 mm glue socket 16bar grey

£9.09
Profec Cross-piece PVC-U 20 mm glue socket 16bar grey
0110375
Profec Cross-piece PVC-U 20 mm glue socket 16bar grey

£1.62
VDL Reducer bush PVC-U 63 mm x 1" glue spigot x female thread 16bar grey
0110793
VDL Reducer bush PVC-U 63 mm x 1" glue spigot x female thread 16bar grey

£8.58
Hose tail 2/3 union adaptor PP 3/4" x 10 mm female threaded nut x hose tail 6bar grey
0330227
Hose tail 2/3 union adaptor PP 3/4" x 10 mm female threaded nut x hose tail 6bar grey

£1.62
Profec Backing ring PVC-U 32 mm 16bar DN25 grey PN10/16
0110920
Profec Backing ring PVC-U 32 mm 16bar DN25 grey PN10/16

£3.32
Profec Pipe clamp PP 40 mm black type 3
0110954
Profec Pipe clamp PP 40 mm black type 3

£0.94
VDL Pipe clamp PP 125 mm black type C
0110960
VDL Pipe clamp PP 125 mm black type C

£8.88

Technical details

  • Colour
    black/red
  • Maximum ambient temperature
    40 °C
  • Size
    DN100
  • Pressure
    10 bar
  • Impellers
    1
  • Material impeller 1
    fibreglass-reinforced PES
  • Ampere
    5.5 A
  • Voltage
    230VAC
  • Connection
    flange
  • Minimum medium temperature (continuous)
    -10 °C
  • Frequency
    50 Hz
  • Approval
    WRAS
  • Minimum ambient temperature
    0 °C
  • Type
    MAGNA3 100-100F (450)
  • Max. temperature
    110 °C
  • Pump body
    cast iron
  • Material
    cast iron
  • EAN
    4019305785624
  • Part number
    7039829
  • Manufacturer
    Grundfos

Barcode

4019305785624

Variants

Part number
Price
Box qty
MSQ
Stock
No variants found
Adjust or clear the selected filters to see available variants.
7039796
0.074 kW
4 m
£1,111.00
1
1
7039797
0.11 kW
6 m
£1,300.00
1
1
7039798
0.144 kW
8 m
£1,373.00
1
1
7039799
0.18 kW
10 m
£1,562.00
1
1
7039800
0.336 kW
12 m
£2,592.00
1
1
7039801
0.097 kW
4 m
£1,384.00
1
1
7039802
0.178 kW
6 m
£1,511.00
1
1
7039803
0.265 kW
8 m
£2,146.00
1
1
7039804
0.348 kW
10 m
£2,362.00
1
1
7039805
0.44 kW
12 m
£2,704.00
1
1
7039806
0.608 kW
15 m
£3,206.00
1
1
7039807
0.607 kW
18 m
£3,687.00
1
1
7039808
0.139 kW
4 m
£2,858.00
1
1
7039809
0.249 kW
6 m
£3,367.00
1
1
7039810
0.325 kW
8 m
£3,706.00
1
1
7039811
0.429 kW
10 m
£3,923.00
1
1
7039812
0.536 kW
12 m
£4,141.00
1
1
7039813
0.63 kW
15 m
£4,770.00
1
1
7039814
0.762 kW
18 m
£5,594.00
1
1
7039815
0.194 kW
6 m
£3,584.00
1
1
7039816
0.35 kW
6 m
£4,092.00
1
1
7039817
0.478 kW
8 m
£4,455.00
1
1
7039818
0.613 kW
10 m
£4,699.00
1
1
7039819
0.769 kW
12 m
£5,038.00
1
1
7039820
1.301 kW
15 m
£5,307.00
1
1
7039821
0.326 kW
4 m
£4,287.00
1
1
7039822
0.53 kW
6 m
£4,721.00
1
1
7039823
0.721 kW
8 m
£5,084.00
1
1
7039824
1.041 kW
10 m
£5,084.00
1
1
7039825
1.297 kW
12 m
£5,708.00
1
1
7039826
0.465 kW
4 m
£5,038.00
1
1
7039827
0.664 kW
6 m
£5,496.00
1
1
7039828
0.971 kW
8 m
£5,463.00
1
1
7039829
1.244 kW
10 m
£5,952.00
1
1
7039830
1.576 kW
12 m
£6,751.00
1
1
